PaymentForm

PROCASH · Payment API v5.8.2 · Developer documentation

"The focus is on merchants, the priority is their profitability, the goal is innovation and pragmatism."

🔒 PCI SAQ-A ↗ Redirect ⬜ Embedded (iframe) ⇄ S2S 💳 Installments 📱 QR 🇦🇷 ARS · Argentina

PaymentForm is the hosted payment form by PROCASH. Your site never sees card data: the form is served from a PCI-compliant domain. You only execute two server-to-server calls from your backend: OrderInitial to create the order and OrderFinal to confirm the result.

⇄

Only 2 S2S calls

OrderInitial to create the order, OrderFinal to confirm the result. Everything else is automatic.

🔒

PCI SAQ-A included

Your server never sees or processes card data. The PCI scope is minimal by design.

🔀

2 integration modes

Full redirect (simpler) or embedded iframe with postMessage for an experience without leaving your site.

💳

Installments and QR

Native support for installments (1 to N) with configurable financial plans per acquirer. Dynamic QR payments available depending on the platform configuration.

🇦🇷

Argentine context

Currency ARS (032) · Amounts in cents · CUIT/CUIL as tax identifier · Time zone UTC-3 (Buenos Aires).

Payment flow

How it works

Complete sequence diagram: actors, calls, and data flow.

🖥️ Your siteMerchant / Backend

⚡ GatewayCore API

💳 PaymentFormHosted form

👤 BuyerBrowser

POST /OrderInitial

amount, currency, MerchantRedirectURL, MerchantNotifyURL

InitialToken + InitialIdentification

+ CustomerRedirectAddress — save InitialIdentification in your DB

3 · Redirect 302 → CustomerRedirectAddress?token=…

Merchant redirects the browser to the hosted form

4 · Opens PaymentForm

5 · Form retrieves configuration (internal)

6 · Enters card details

7 · Form processes payment (internal)

8 · Redirect → MerchantRedirectURL?token=…

9 · Browser returns to your site

10 · POST /OrderFinal (InitialIdentification)

11 · AuthCode, Tickets, confirmed amount

ℹ️

Golden rule: The redirect result (steps 8–9) is only a navigation signal. The actual and final result is always obtained via OrderFinal (steps 10–11) from your server.

Integration options

Integration modes

PaymentForm supports three modes depending on the level of UX control and integration you need. All three maintain PCI SAQ-A compliance — the merchant never captures card data.

↗️

Mode A — Redirect

The buyer's browser leaves your site and goes to the hosted form. The simplest and fastest integration mode.

✓ PCI SAQ-A Easiest

⬜

Mode B — Embedded (full iframe)

The complete form is displayed in a cross-origin iframe within your page. Communication via postMessage.

✓ PCI SAQ-A Better UX

UNDER CONSTRUCTION

🧩

Mode C — Hosted Fields

Only the card fields (PAN + CVV) go into a PROCASH iframe. The merchant builds the rest of the form — maximum layout control, without touching CHD.

✓ PCI SAQ-A Maximum control Designed · implementing

You redirect the buyer using the CustomerRedirectAddress returned by OrderInitial. The form processes the payment and returns the buyer to your MerchantRedirectURL.

Node.js / Express

// 1. Call OrderInitial from your server
const response = await fetch('https://api.procash.dev/OrderInitial', {
  method: 'POST',
  headers: {
    'Content-Type': 'application/json',
    'Authorization': `Bearer ${API_KEY}`
  },
  body: JSON.stringify({
    OrderInitial: {
      MerchantSystemID: 'SHOP-01',      // required
      MerchantCompanyID: '0',          // required
      TransactionAmount: 1000000,      // $10,000.00 ARS (in cents)
      CurrencyCode: '032',            // desirable — if omitted assumes ARS
      ReferenceNumber: 'ORD-2026-0001',
      MerchantRedirectURL: 'https://www.mi-tienda.com.ar/pago/retorno', // optional
      MerchantNotifyURL: 'https://www.mi-tienda.com.ar/webhooks/pago',   // recommended
      FacilityNumber: 3,              // optional — cuotas (1 = contado)
    }
  })
});
const { OrderInitialResponse: r } = await response.json();

// 2. Verify that the order was created successfully
//    ResponseActions is the source of truth — must contain "OK"
//    ResponseCode "-1" is the success indicator in this contract
if (!r.ResponseActions?.includes('OK') || r.ResponseCode !== '-1') {
  // Order rejected by the platform — do not redirect
  throw new Error(`OrderInitial failed: [${r.ResponseActions}] ${r.ResponseMessage}`);
}

// 3. Validate presence of required fields in the response
if (!r.InitialIdentification || !r.CustomerRedirectAddress) {
  throw new Error('Incomplete response: missing InitialIdentification or CustomerRedirectAddress');
}

// 4. ⚠️ Save InitialIdentification in your DB BEFORE redirecting
//    It is PRIVATE — it never travels to the browser
await db.orders.update({ referenceNumber: 'ORD-2026-0001' }, {
  initialIdentification: r.InitialIdentification
});

// 5. Redirect the buyer to the form — only the InitialToken (PUBLIC) travels in the URL
res.redirect(302, r.CustomerRedirectAddress);

Embed the form in your page with an iframe using the same URL. Listen to postMessage events — card data never leaves the iframe.

📡

Available postMessage events:
paymentform:ready · paymentform:resize · paymentform:submitted · paymentform:error

HTML + JavaScript

<!-- iframe cross-origin — PCI SAQ-A maintained -->
<iframe
  id="payment-frame"
  src="https://payment.procash.dev/?token=INITIAL_TOKEN_AQUI"
  style="width:100%;border:none;min-height:420px;"
  allow="payment"
></iframe>

<script>
window.addEventListener('message', (e) => {
  // Always verify origin
  if (e.origin !== 'https://payment.procash.dev') return;

  const { type, result } = e.data;

  if (type === 'paymentform:submitted') {
    if (result === 'approved') {
      // Call your backend to execute OrderFinal
      confirmOrder(result);
    } else if (result === 'refused') {
      showRefusedMessage();
    }
  }

  if (type === 'paymentform:resize') {
    document.getElementById('payment-frame').style.height = e.data.height + 'px';
  }
});
</script>

🚧

Status: designed and under construction (Phase 16). The v1.0.0 integration contract is defined and the client-side logic (embed-fields.ts) is implemented. The cross-origin subdomain infrastructure and WASM→JWE encryption are pending. Consult the PROCASH team for availability in sandbox.

¿Qué es Hosted Fields?

Instead of embedding the complete form, only the sensitive fields (PAN + CVV) are in a cross-origin iframe served by PROCASH. Your page builds the rest of the checkout — amount, installments, buyer details, layout — while card data never touches your DOM.

// Your page (out of PCI scope)
YOUR FORM
[ Amount: $10,000.00 ARS ]
[ Installments: 3 interest-free  ]
⬛ PROCASH IFRAME (cross-origin · PROCASH SAQ-D scope)
[ PAN:  ________________ ]
[ CVV:  ___ ]  [ Exp: __/__ ]
→ WASM encrypts to JWE before leaving
[ Cardholder name: ________ ]
[ Pay → ]
↕ postMessage: "ready" · "fieldValidity" · "submit" · "error" · "challenge"

Tiers de hosting disponibles

Tier	Iframe domain	Who is it for
T1 — Compartido	`{tenant}.payment.procash.dev`	Default — quick onboarding
T2 — White-label	`pay.tudominio.com` (CNAME → PROCASH)	Merchants with their own branding
T3 — Enterprise	Dominio completamente custom	Banks / large retailers (regional/on-prem hosting)

Contrato postMessage (eventos del iframe)

Event	Direction	Payload
`paymentform:ready`	iframe → parent	`{ mode: 'fields' }` — iframe ready to receive interaction
`paymentform:fieldValidity`	iframe → parent	`{ field: 'pan'\|'cvv', valid: bool }` — to enable/disable the button
`paymentform:resize`	iframe → parent	`{ height: px }` — adjust iframe height
`paymentform:submit`	parent → iframe	`{ token }` — submit trigger from your button
`paymentform:submitted`	iframe → parent	`{ result: 'approved'\|'refused'\|'challenge' }`
`paymentform:error`	iframe → parent	`{ code, message }`

HTML + JavaScript — Hosted Fields (Model C)

<!-- Only the sensitive fields iframe (cross-origin) -->
<div id="checkout">
  <!-- Your UI: amount, installments, cardholder name -->
  <p>Total: <strong>$10.000,00 ARS</strong> en 3 cuotas</p>

  <!-- PROCASH iframe: PAN + CVV only -->
  <iframe
    id="fields-frame"
    src="https://{tenant}.payment.procash.dev/fields?token=INITIAL_TOKEN"
    style="width:100%;border:none;height:120px;"
    allow="payment"
    sandbox="allow-scripts allow-same-origin"
  ></iframe>

  <!-- Your own payment button -->
  <input type="text" placeholder="Cardholder name" id="cardName">
  <button id="pay-btn" disabled>Pay</button>
</div>

<script>
const frame = document.getElementById('fields-frame');
const payBtn = document.getElementById('pay-btn');
let panOk = false, cvvOk = false;

// Listen to iframe events
window.addEventListener('message', (e) => {
  if (e.origin !== 'https://{tenant}.payment.procash.dev') return;
  const { type, field, valid, height, result } = e.data;

  if (type === 'paymentform:resize')
    frame.style.height = height + 'px';

  if (type === 'paymentform:fieldValidity') {
    if (field === 'pan') panOk = valid;
    if (field === 'cvv') cvvOk = valid;
    payBtn.disabled = !(panOk && cvvOk);  // enable only if both OK
  }

  if (type === 'paymentform:submitted' && result === 'approved')
    confirmOrder();  // call your backend → OrderFinal
});

// Your button triggers the submit in the iframe
payBtn.addEventListener('click', () => {
  frame.contentWindow.postMessage(
    { type: 'paymentform:submit' },
    'https://{tenant}.payment.procash.dev'
  );
});
</script>

🔒

Security: the iframe encrypts PAN + CVV using WASM → JWE before they leave the iframe. Your page never sees the plaintext data, even though they share the same browser window. The iframe's sandbox and allow-same-origin are configured by the platform so that postMessage communication works without exposing the sensitive DOM.

Integration guide

Step by step

Follow these steps to integrate PaymentForm in your backend.

OrderInitial (S2S)

Call from your server to create the payment order. Never from the browser.

POST https://api.procash.dev/OrderInitial

Auth: Authorization: Bearer {API_KEY}

Request JSON

{
  "OrderInitial": {
    "MerchantSystemID": "SHOP-01",       // required
    "MerchantCompanyID": "0",           // required
    "TransactionAmount": 1000000,       // $10,000.00 ARS (in cents)
    "CurrencyCode": "032",              // desirable — if omitted assumes ARS
    "ReferenceNumber": "ORD-2026-0001", // your internal order ID
    "MerchantRedirectURL": "https://www.mi-tienda.com.ar/pago/retorno", // optional
    "MerchantNotifyURL": "https://www.mi-tienda.com.ar/webhooks/pago",   // recommended
    "FacilityNumber": 3,               // optional — cuotas (1 = contado)
    "Products": [
      { "Code": "PLAN-PRO", "Name": "Plan Pro Mensual", "Quantity": 1, "UnitAmount": 1000000 }
    ]
  }
}

Response JSON

{
  "OrderInitialResponse": {
    "ResponseActions": ["OK"],          // ← source of truth
    "ResponseCode": "-1",                 // ← informational (-1 = OK in this contract)
    "ResponseMessage": "Orden creada",     // ← informational
    "InitialToken": "11111111-1111-5111-8111-111111111111",
    "InitialIdentification": "99999999-9999-5999-8999-999999999999",
    "CustomerRedirectAddress": "https://payment.procash.dev/?token=11111111-1111-5111-8111-111111111111",
    "MerchantRedirectURL": "https://www.mi-tienda.com.ar/pago/retorno",
    "TransactionValidThru": "2026-06-04T23:59:59-03:00", // UTC-3 · Buenos Aires
    "Sequence": ""
  }
}

ℹ️

ResponseActions is the source of truth. ResponseCode and ResponseMessage are informational — they are always present but must not be used as decision criteria.

⚠️

Critical: Save InitialIdentification in your database associated with the order. It is PRIVATE — never send it to the browser or expose it in URLs.

Redirect the buyer

Use CustomerRedirectAddress (which already has the token embedded). Equivalent to https://payment.procash.dev/?token={InitialToken}

Express / Node.js

const { OrderInitialResponse: r } = await orderInitial(); // see Step 1

// ✅ Only redirect if ResponseActions contains "OK" and ResponseCode is "-1"
if (r.ResponseActions?.includes('OK') && r.ResponseCode === '-1'
    && r.InitialIdentification && r.CustomerRedirectAddress) {
  res.redirect(302, r.CustomerRedirectAddress);
} else {
  // Handle error — the order was not created
  res.status(400).json({ error: r.ResponseMessage });
}

The form processes the payment (internal)

The form manages all payment processing internally — it retrieves the order configuration, captures the buyer's card details, and processes the transaction against the platform. No code is required on your part in this step.

🔒

Your site never sees or touches card details. Everything occurs within the PROCASH PCI environment.

Return to your site

The browser returns to your MerchantRedirectURL. The redirect does not include the payment result — the status is always retrieved using OrderFinal (or OrderStatus) from your server.

Return URL (what reaches the browser)

https://www.mi-tienda.com.ar/pago/retorno
  ?token=11111111-1111-5111-8111-111111111111
  // ← no status, no result — only the public token
  // The actual result is obtained by calling OrderFinal from your server

⚠️

The redirect does not carry the result. Never assume approved/rejected simply because the buyer returned to your site. Always execute OrderFinal (S2S) to get the actual result. The webhook (MerchantNotifyURL) also confirms it asynchronously.

💡

No MerchantRedirectURL: if you omit this field in OrderInitial, there is no redirect. The form shows the result directly on screen. In that case, use the webhook (MerchantNotifyURL) and/or OrderStatus to find out the result in your backend.

OrderFinal (S2S)

Confirm the result from your server using the InitialIdentification you saved in Step 1.

POST https://api.procash.dev/OrderFinal

Request JSON

{
  "OrderFinal": {
    "InitialIdentification": "99999999-9999-5999-8999-999999999999"
  }
}

Response JSON — Approved

{
  "OrderFinalResponse": {
    "ResponseActions": ["OK", "Approve", "Tickets", "Completed"], // ← source of truth
    //  OK        → successful operation
    //  Approve   → payment approved
    //  Tickets   → there are receipts to render
    //  Completed → full cycle: OrderInitial→form→OrderFinal executed
    "ResponseCode": "-1",                                      // ← informational (-1 = aprobado)
    "ResponseMessage": "Aprobado",                               // ← informational
    "AuthCode": "AUTH123",
    "TransactionAmount": 1000000,
    "CurrencyCode": "032",
    "Tickets": [
      { "Type": "Customer", "Content": "..." },
      { "Type": "Merchant", "Content": "..." }
    ]
  }
}

Response JSON — Refused

{
  "OrderFinalResponse": {
    "ResponseActions": ["OK", "Refuse", "Completed"], // ← source of truth — pago NO acreditado
    //  OK        → operation processed
    //  Refuse    → refused by issuer
    //  Completed → full cycle executed (same as in Approve)
    "ResponseCode": "05",                              // ← informational, solo un ejemplo — puede ser cualquier código
    "ResponseMessage": "Tarjeta rechazada por el emisor", // ← informational, solo un ejemplo
    "TransactionAmount": 1000000,
    "CurrencyCode": "032"
  }
}

ℹ️

Decision logic — ResponseActions is always an array:

OK → always present along with Approve or Refuse. Approve → payment approved · confirm and deliver. Refuse → refused · not charged · notify buyer. Completed → full cycle: merchant executed OrderFinal and closed integration cycle. Tickets → there are receipts in Tickets[] to render to buyer.

Do not use ResponseCode or ResponseMessage as decision criteria. Correct logic: includes('Approve') for approved · includes('Refuse') for refused · includes('Completed') for closed cycle.

📡 Webhook — MerchantNotifyURL

The Core calls your MerchantNotifyURL asynchronously with the payment result. It guarantees that you receive the result even if the browser does not return to your site.

🔁 May arrive more than once — make it idempotent ✓ Use it alongside OrderFinal 📬 Verify signature if available

Visual Customization

Form Look & Feel

PaymentForm fully adapts to the merchant's branding. Styles, interface model, products, and logo are configured per order, directly in the OrderInitial via AdditionalInformation — without touching form code.

ℹ️

Styles travel in AdditionalInformation[].Name = "PaymentForm.Styles" with the styles JSON in Base64. Merchant branding (name + logo) goes in Name = "PaymentForm.Company". Both are sent in OrderInitial and the form applies them with priority over the base configuration.

Modelos de interfaz

Selected with FormMode in the configuration. You can combine any model with any color theme.

Screenshots — the same order in the four combinations

Con tarjeta y con productos — With card · with products
`interactive-card` · `ShowProducts:true`

Con tarjeta sin productos — With card · without products
`interactive-card` · `ShowProducts:false`

Sin tarjeta con productos — Without card · with products
`classic` · `ShowProducts:true`

Sin tarjeta sin productos — Without card · without products
`classic` · `ShowProducts:false`

How to configure styles from OrderInitial

Styles are sent in AdditionalInformation as Base64 JSON. The form applies them with priority over any default configuration.

⚠️

Important (JSON Structure): The form rendering engine only supports three root objects inside the styles array: Background, Text, and Form. Any input or card styling properties must be configured inside these blocks (for example, use Form.input_color instead of a standalone Input object). Legacy root objects like Card or Input are not recognized and will be ignored.

Step 1 — Build the styles object

// Styles object (flat JSON before encoding)
const stylesArray = [
  { "Background": { "color": "#fcf9fb" } },
  { "Text": { "color": "#130a25" } },
  {
    "Form": {
      "background_color": "#fcf9fb",
      "button_color": "#a47fab",
      "price_color": "#68ac5c",
      "error_color": "#dc2626",
      "border_radius": "10px",
      "max_width": "520px",
      "input_color": "#ffffff",
      "input_innertext_color": "#130a25",
      "input_border_color": "#f3f3f4",
      "form_label": "orden",         // "pedido" | "orden" | "operacion" | "transaction"
      "show_cft": true,
      "show_tea": false,
      "show_interest_rate": true,
      "show_installment_calculation": false,
      "installment_calculation_mode": "simple"
    }
  }
];

const stylesB64 = btoa(JSON.stringify(stylesArray));  // encode to Base64

// Merchant branding
const companyB64 = btoa(JSON.stringify({
  "Name": "Tu Comercio",
  "LogoUrl": "https://www.mi-tienda.com.ar/logo.png"   // Public URL — requires access from the buyer's browser
  // — or —
}));

// Real example of Data URI with an SVG icon (64×64, background #004785)
// You can generate yours with: btoa(svgString) in the browser, or base64.b64encode(svg.encode()).decode() in Python
  // PNG: icon + white on background #004785 (32×32 px)
  "iVBORw0KGgoAAAANSUhEUgAAACAAAAAgCAIAAAD8GO2jAAAAc0lEQVR42u3WWw4AERQDULuzMuvmW+J1S+sRN36nJ0Zm1LnjxgdCYnsRo3HGFG1m4PQhYzK9Y9SfiaWxG1yguWszUDC4QO/cECAzxEBE51lg7I0jQM34Z7D/OyAA9//snrhwFHeyolUoepGi2Ym66Yp2nQBekRDCxivTugAAAABJRU5ErkJggg==";

Step 2 — Include them in OrderInitial

{
  "OrderInitial": {
    "MerchantSystemID": "SHOP-01",
    "MerchantCompanyID": "0",
    "TransactionAmount": 1000000,
    "CurrencyCode": "032",
    "ReferenceNumber": "ORD-2026-0001",
    "Products": [
      {
        "Code": "PLAN-PRO",
        "Name": "Plan Pro Mensual",
        "Quantity": 1,
        "UnitAmount": 1000000,
        // ↑ Real PNG 32×32 px — icon + white on background #004785 — 172 bytes / 232 chars base64
      }
    ],
    "AdditionalInformation": [
      {
        "Name": "PaymentForm.Styles",
        "Value": "<stylesB64>"   // result of btoa(JSON.stringify(stylesArray))
      },
      {
        "Name": "PaymentForm.Company",
        "Value": "<companyB64>"  // result of btoa(JSON.stringify(companyObj))
      }
    ]
  }
}

Available style tokens

Token	Object	Description	Example
`color`	`Background`	Page background color	`#fcf9fb` · `#0f172a`
`color`	`Text`	Main card text color	`#130a25` · `#ffffff`
`background_color`	`Form`	Form card background color	`#fcf9fb` · `#ffffff`
`button_color`	`Form`	Color of the "Pay" button	`#a47fab` · `#004785`
`price_color`	`Form`	Color of the total amount	`#68ac5c` · `#22c55e`
`error_color`	`Form`	Color of validation error messages	`#dc2626` · `#fb7185`
`input_color`	`Form`	Background color of input fields	`#ffffff` · `#f8fafc`
`input_innertext_color`	`Form`	Color of the text entered in fields	`#130a25` · `#0f172a`
`input_border_color`	`Form`	Border color of input fields	`#f3f3f4` · `#e2e8f0`
`border_radius`	`Form`	Form card border radius	`10px` · `0`
`max_width`	`Form`	Maximum form width	`520px`
`form_label`	`Form`	Form title / label context	`orden` · `pedido` · `operacion` · `transaction`
`show_cft`	`Form`	Enables/Disables showing the Total Financial Cost (CFT) in the installment selector	`true` · `false`
`show_tea`	`Form`	Enables/Disables showing the Annual Effective Rate (TEA) in the installment selector	`true` · `false`
`show_interest_rate`	`Form`	Enables/Disables showing the Annual Nominal Rate (TNA) in the installment selector	`true` · `false`
`show_installment_calculation`	`Form`	If true, calculates the value of each installment applying the plan's interest rate instead of a simple division	`true` · `false`
`installment_calculation_mode`	`Form`	Formula used to calculate the installment with interest: simple (direct interest), french_tna (French TNA), french_tea (French TEA), cft (French CFT)	`simple` · `french_tna` · `french_tea` · `cft`
`header_align`	`Form`	Horizontal alignment of the order header	`left` · `center` · `right`
`header_font`	`Form`	Font family of the order header	`Outfit, sans-serif`
`header_size`	`Form`	Font size of the order header	`14px` · `0.875rem`
`header_color`	`Form`	Font color of the order header	`#475569`
`button_align`	`Form`	Alignment and stretching of the pay button	`flex-start` · `center` · `flex-end` · `stretch`
`button_width`	`Form`	Explicit width of the pay button	`200px` · `100%`
`button_padding`	`Form`	Inner padding of the pay button	`12px 24px`
`button_font_size`	`Form`	Font size of the pay button	`16px`
`button_icon_url`	`Form`	Custom icon URL to replace the default padlock on the button	`https://example.com/shield.png`
`amount_font`	`Form`	Font family of the amount text	`Inter, sans-serif`
`amount_font_size`	`Form`	Font size of the amount text	`24px` · `1.5rem`
`amount_color`	`Form`	Font color of the amount text	`#16a34a`

💡

Configuration Note: The following properties correspond to the default Tenant (merchant/platform) configuration. However, you can dynamically override them for each transaction by sending them in the style JSON (PaymentForm.Styles) inside the "Form" block (e.g., Styles[].Form.form_mode). If not sent, the platform will apply the pre-configured values for your account or the form's default values.

Form configuration

Field	Type	Default	Description
`FormMode`	string	`classic`	`classic` — traditional form · `interactive-card` — interactive 3D card (premium)
`ShowProducts`	boolean	`true`	Shows or hides product details. If `false`, the form is more compact.
`AllowInstallments`	boolean	`true`	Enables the installment selector. Available plans are determined by the card's BIN.
`AllowAmountEdit`	boolean	`false`	Allows the buyer to modify the amount before paying.
`ProductLayout`	string	`list`	`list` — vertical · `grid` — 2-column grid · `compact` — without images, ideal for large carts
`Locale`	string	`es-AR`	Language and format. `es-AR` · `en-US` · `pt-BR`. Changes labels, date and currency formats.

🖼️

Product images: the ImageUrl field in Products[] accepts a public URL or base64 Data URI. When base64 is used, the image does not generate external network requests — strict PCI compliance. Images can also come in the Products[] returned by the Core.

Preview — Data URI rendered in the browser

32×32 · PNG · 172 bytes

Plan Pro Mensual

SKU: PLAN-PRO · x1

$10.000

The string that travels in ImageUrl:

             (232 chars · PNG 32×32 px)


Format: data:<mime>;base64,<data> — RFC 2397. The header iVBORw0KGgo always identifies a PNG (magic bytes \x89PNG). Supports image/png, image/jpeg, image/webp, image/svg+xml.

How to generate the Data URI?

// Browser (JS)
const
 reader = new
 FileReader();

            reader.onload = e => console.log
(e.target.result);

            reader.readAsDataURL(imageFile);


# Python
import
 base64

            with open
("logo.png", "rb") as f:

              b64 = base64.b64encode(f.read()).decode()


# Node.js

            const fs = require('fs');

            const b64 = fs.readFileSync('logo.png')

              .toString('base64');


Sandbox & Testing

Test data

Use these cards and scenarios in the PROCASH sandbox environment.

Tarjetas de prueba

Card number	Brand	CVV	Expiration	Result
`4111 1111 1111 1111`	Visa	`123`	`12/28`	✅ Approved
`4000 0000 0000 0002`	Visa	`123`	`12/28`	❌ Refused
`5555 5555 5555 4444`	Mastercard	`123`	`12/28`	✅ Approved
`5105 1051 0510 5100`	Mastercard	`123`	`12/28`	❌ Refused

ResponseActions — valores posibles

ResponseActions is an array — it can always contain multiple values at once. OK and Completed always accompany Approve or Refuse when the cycle is complete.

ResponseActions (array)	ResponseCode	Meaning
`["OK", "Approve", "Completed"]`	`-1`	✅ Payment approved · closed cycle
`["OK", "Approve", "Tickets", "Completed"]`	`-1`	✅ Approved + receipts available
`["OK", "Refuse", "Completed"]`	`05` (ej.)	❌ Refused — the code is informational and may vary
⚠️ The values of `ResponseCode` are only examples. There is a wide variety of possible codes depending on the issuer and the platform. The source of truth is always the action `Refuse` or `Error` in ResponseActions — this is the real indicator that the payment was not approved, regardless of the code.

💡

Correct code logic:
actions.includes('Approve') → approved, credit/deliver.
actions.includes('Refuse') → refused, not charged.
actions.includes('Completed') → the merchant executed OrderFinal and closed the cycle.
actions.includes('Tickets') → render Tickets[] to the buyer.

Payment NOT approved: includes('Refuse') or includes('Error') are the only real indicators of refusal. ResponseCode and ResponseMessage are informational and may vary — never use them as decision criteria.

Escenarios de prueba

Configurable scenarios in sandbox — consult the PROCASH team to activate them.

baseline

Standard approved flow without friction

refused-response

Response refused by issuer

3ds-frictionless

3DS without challenge — automatic approval

3ds-snap-challenge

3DS with interactive challenge

high-risk

High risk transaction — additional review

Métodos de pago en sandbox

Method	Available in sandbox	Notes
💳 Credit card (installments)	✅ Yes	Visa, Mastercard, Amex · up to 12 installments depending on the BIN plan
💳 Debit card	✅ Yes	Single installment · PIN not required in CNP channel
📱 Dynamic QR	⚡ Depending on config	Requires enablement on the platform · consult the PROCASH team
🏦 Transfer / CVU	⚡ Depending on config	Available if the plan includes it · the form shows the destination CVU

Endpoints Sandbox

S2S https://api.procash.dev · Gateway / Core API

WEB https://payment.procash.dev · PaymentForm (hosted form)

API Reference

Quick reference

Key fields of the OrderInitial request.

Field	Type	Required	Description
`MerchantSystemID`	string	✅ Yes	Merchant system identifier
`MerchantCompanyID`	string	✅ Yes	Company ID
`MerchantBranch`	string	N/A	Not used in CNP web integration. The platform resolves it by merchant configuration.
`MerchantPOSID`	string	N/A	Not used in CNP web integration. The platform resolves it by merchant configuration.
`TransactionAmount`	integer	✅ Yes	Amount in cents (e.g. 1000000 = $10,000.00 ARS)
`CurrencyCode`	string	⚡ Desirable	ISO 4217 — `032` = ARS (Argentine Pesos). If omitted, the platform assumes the currency of the merchant's country. Always recommended to send.
`ReferenceNumber`	string	✅ Yes	Your internal order ID (for reconciliation)
`MerchantRedirectURL`	string	Opcional	URL to which the buyer returns after payment. If omitted, there is no redirect: the form directly shows the final result (approved / refused) without leaving the form page.
`MerchantNotifyURL`	string	⚡ Recom.	Webhook — the Core notifies the result asynchronously
`Products`	array	Opcional	Product details to display on the form
`FacilityNumber`	integer	Opcional	Number of installments (1 = single payment, 3/6/12… = installments). Requires a financial plan enabled for the BIN.
`TaxIdentification`	string	Opcional	Tax identifier of the buyer — CUIT/CUIL for Argentina (e.g. `20-12345678-9`)

Montos en ARS — formato

The TransactionAmount field is in cents (without decimal comma). Use the dot as thousands separator and the comma for decimals when displaying to the user.

Monto para el usuario	TransactionAmount	Nota
$1.000,00 ARS	`100000`	One thousand pesos
$5.000,00 ARS	`500000`	Five thousand pesos
$10.000,00 ARS	`1000000`	Ten thousand pesos
$50.000,00 ARS	`5000000`	Fifty thousand pesos
$100.000,00 ARS	`10000000`	One hundred thousand pesos

💡 To convert: TransactionAmount = Math.round(montoPesos * 100)

Flujo resumido

1️⃣

OrderInitial

Tu server → Gateway
Get token + ID

2️⃣

Redirect

Browser → PaymentForm
Buyer enters card

3️⃣

Retorno

Browser → your MerchantRedirectURL
+ async webhook

4️⃣

OrderFinal

Your server → Gateway
Confirm the actual result

✅

Questions? Contact the PROCASH integration team. Mention contract number PROCASH Payments API v5.8.2 in your inquiry.

Optional elements of OrderInitial

Seller · Payer · Customer · Shipping

OrderInitial accepts four optional objects that enrich the transaction with data from the involved parties. All are optional — including them allows for better traceability, anti-fraud analysis, and regulatory compliance.

ℹ️

Payer vs Customer: if Payer is not present, the platform takes the data from Customer as the payer. In most e-commerce cases, they are the same person — sending Customer is sufficient.

Data of the buyer/customer. It is the most common object in e-commerce. If Payer is not sent, these details are also used as the payer.

Campo	Tipo	Descripción
`FirstName`	string	First name
`LastName`	string	Last name
`MiddleName`	string	Middle name(s)
`Email`	string	Customer's email
`Phone`	string	Phone number
`DocumentType`	enum	`CI` · `PAS` · `ACCOUNT_NUMBER` · `CONTRACT` · `OTHER`
`DocumentNumber`	string	Document number
`TaxIdentificationType`	string	Type of tax identifier — in Argentina: `CUIT` or `CUIL`
`TaxIdentification`	string	CUIT/CUIL number or other tax identifier
`AddressStreet`	string	Street
`AddressNumber`	string	Street number
`AddressInternal`	string	Floor, apartment, unit
`AddressSuburb`	string	Neighborhood
`City`	string	City
`State`	string	State / province
`Country`	string	Country
`ZipCode`	string	Zip code
`NotifyURL`	string	Notification URL specific to the customer

Example — Customer in OrderInitial (Argentina)

{
  "OrderInitial": {
    "MerchantSystemID": "SHOP-01",
    "MerchantCompanyID": "0",
    "TransactionAmount": 1000000,
    "CurrencyCode": "032",
    "ReferenceNumber": "ORD-2026-0001",
    "Customer": {
      "FirstName": "María",
      "LastName": "González",
      "Email": "maria.gonzalez@email.com",
      "Phone": "1123456789",
      "DocumentType": "CI",
      "DocumentNumber": "12345678",
      "TaxIdentificationType": "CUIL",
      "TaxIdentification": "27-12345678-3",
      "AddressStreet": "Av. Corrientes",
      "AddressNumber": "1234",
      "AddressInternal": "Piso 3 Dpto B",
      "City": "Buenos Aires",
      "State": "CABA",
      "Country": "AR",
      "ZipCode": "C1043"
    }
  }
}

Data of the payer — the person making the payment with their card. Same schema as Customer. Only necessary when the payer is different from the buyer (e.g. someone paying on behalf of another).

Campo	Tipo	Descripción
`FirstName`	string	First name del pagador
`LastName`	string	Last name del pagador
`Email`	string	Payer's email
`Phone`	string	Payer's phone
`DocumentType`	enum	`CI` · `PAS` · `ACCOUNT_NUMBER` · `CONTRACT` · `OTHER`
`DocumentNumber`	string	Document number del pagador
`TaxIdentificationType`	string	Type of tax identifier — in Argentina: `CUIT` or `CUIL`
`TaxIdentification`	string	Payer's CUIT/CUIL number
`AddressStreet` · `AddressNumber` · `City` · `State` · `Country` · `ZipCode`	string	Payer's full address
`NotifyURL`	string	Notification URL specific to the payer

💡

In most e-commerce cases, the buyer and the payer are the same person — just send Customer and omit Payer. The platform will automatically use Customer as the payer.

Seller details. Useful in marketplace models or when the merchant needs to identify the specific seller within the platform.

Campo	Tipo	Descripción
`FirstName`	string	Seller's name
`LastName`	string	Last name del vendedor
`Email`	string	Seller's email
`DocumentType`	enum	`CI` · `PAS` · `ACCOUNT_NUMBER` · `CONTRACT` · `OTHER`
`DocumentNumber`	string	Document number del vendedor
`TaxIdentificationType`	string	Type of tax identifier — in Argentina: `CUIT`
`TaxIdentification`	string	Seller's CUIT
`Identification`	string	Internal identifier of the seller on the platform
`IdentificationType`	enum	Identifier type: `CI` · `PAS` · `ACCOUNT_NUMBER` · `CONTRACT` · `OTHER`
`AddressStreet` · `AddressNumber` · `City` · `State` · `Country`	string	Seller's address

Example — Seller in OrderInitial (marketplace)

{
  "OrderInitial": {
    // ... base fields ...
    "Seller": {
      "Identification": "SELLER-0042",
      "IdentificationType": "CONTRACT",
      "FirstName": "Distribuidora",
      "LastName": "Sur S.A.",
      "TaxIdentificationType": "CUIT",
      "TaxIdentification": "30-71234567-8",
      "Email": "ventas@distribuidorasur.com.ar"
    }
  }
}

Delivery address of the order. Independent of the buyer's billing address. Necessary when physical shipping is part of the flow.

Campo	Tipo	Max	Descripción
`FirstName`	string	100	Recipient's name
`LastName`	string	100	Last name del destinatario
`Address1`	string	255	Primary address (street and number)
`Address2`	string	255	Complement (floor, apartment, unit)
`City`	string	100	City de entrega
`StateProvince`	string	100	Province
`Country`	string	50	Country (ej: `AR`)
`ZipCode`	string	20	Zip code
`PhoneNumber`	string	50	Contact phone number for delivery
`Email`	string	255	Contact email for shipping notifications

Example — Shipping in OrderInitial

{
  "OrderInitial": {
    // ... base fields + Customer ...
    "Shipping": {
      "FirstName": "María",
      "LastName": "González",
      "Address1": "Av. Corrientes 1234",
      "Address2": "Piso 3 Dpto B",
      "City": "Buenos Aires",
      "StateProvince": "CABA",
      "Country": "AR",
      "ZipCode": "C1043",
      "PhoneNumber": "1123456789",
      "Email": "maria.gonzalez@email.com"
    }
  }
}

Ejemplo completo — todos los objetos

OrderInitial with Customer + Shipping (typical Argentina e-commerce case)

{
  "OrderInitial": {
    "MerchantSystemID": "SHOP-01",
    "MerchantCompanyID": "0",
    "TransactionAmount": 1000000,       // $10,000.00 ARS
    "CurrencyCode": "032",
    "ReferenceNumber": "ORD-2026-0001",
    "FacilityNumber": 3,               // 3 installments
    "MerchantRedirectURL": "https://www.mi-tienda.com.ar/pago/retorno",
    "MerchantNotifyURL": "https://www.mi-tienda.com.ar/webhooks/pago",
    "Products": [
      { "Code": "PROD-001", "Name": "Running Shoes", "Quantity": 1, "UnitAmount": 1000000 }
    ],
    "Customer": {              // buyer = payer (most common case)
      "FirstName": "María",
      "LastName": "González",
      "Email": "maria.gonzalez@email.com",
      "Phone": "1123456789",
      "DocumentType": "CI",
      "DocumentNumber": "12345678",
      "TaxIdentificationType": "CUIL",
      "TaxIdentification": "27-12345678-3"
    },
    "Shipping": {             // delivery address (may differ from Customer's)
      "FirstName": "María",
      "LastName": "González",
      "Address1": "Av. Corrientes 1234",
      "Address2": "Piso 3 Dpto B",
      "City": "Buenos Aires",
      "StateProvince": "CABA",
      "Country": "AR",
      "ZipCode": "C1043",
      "PhoneNumber": "1123456789",
      "Email": "maria.gonzalez@email.com"
    }
    // Seller only if it is a marketplace — Payer only if it differs from Customer
  }
}

Integration PortalPaymentForm
